LG 55VH7J-H Full HD Slim Bezel Video Wall

LG 55VH7J-H Full HD Slim Bezel Video Wall

Product code: 55VH7J-H

The ultra slim bezel, with its 1.74mm BtoB (Panel Bezel to Panel Bezel), drastically reduces bezel interference and delivers immersive and seamless content on assembled video wall screens.

SEND AN ENQUIRY

Description

Panel

Screen Size	55"
Panel Technology	IPS
Aspect Ratio	16 : 9
Native Resolution	1,920 x 1,080 (FHD)
Refresh Rate	60Hz
Brightness	700
Contrast Ratio	1,000:1
Dynamic CR	500,000 : 1
Color gamut	NTSC 72%
Viewing Angle (H x V)	178x178
Color Depth	10bit, 1.07Billion colors
Response Time	8 ms (G to G)
Surface Treatment (Haze)	28%
Life Time (Typ.)	60,000Hrs
Life Time (Min.)	50,000Hrs
Operation Hours (Hours / Days)	24/7
Portrait / Landscape	Yes / Yes
OS	webOS 4.1

Additional information

Mechanical Specification

Bezel Color	Black
Bezel Width	B2B : 1.74mm (Panel Bezel to Panel Bezel), 1.3mm(T/L), 0.44mm(B/R) A2A : 2.49mm (Active area to Active area), 1.75mm(T/L), 0.74mm(B/R)
Weight (Head)	18.8 Kg
Packed Weight	31.0 Kg (when individual pallet applied)
Monitor Dimensions (W × H × D)	1,212.2 × 683.0 × 86.9 mm
Carton Dimensions (W × H × D)	1,353 x 855 x 263 mm (Box outer size)
Handle	Yes
VESA™ Standard Mount Interface	600 x 400

Special Feature

IP Rating	IP5X tested

Key Feature

HW	Internal Memory 8 GB, Sensor (Temperature Sensor, BLU Sensor, Acceleration(Gyro) Sensor), Local Key Operation
SW	webOS 4.1, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected®2)), Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready), HDMI-CEC3), SI Server Setting, webRTC, Pro:Idiom, W/B Setting by Grey Scale, Scan Inversion

Internal Memory 8 GB, Sensor (Temperature Sensor, BLU Sensor, Acceleration(Gyro) Sensor), Local Key Operation

webOS 4.1, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected®2)), Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready), HDMI-CEC3), SI Server Setting, webRTC, Pro:Idiom, W/B Setting by Grey Scale, Scan Inversion

Connectivity

Input	HDMI 2 (HDCP 2.2), DP (HDCP 2.2), DVI-D (HDCP 1.4), Audio In, RS-232C In, RJ45 (LAN), IR In, USB 2.0 Type A
Output	DP Out (Input : HDMI / DVI / DP), Audio Out, RS-232C Out, RJ45 (LAN)

Environment Conditions

Operation Temperature	0 °C to 40 °C
Operation Humidity	10 % to 80 %

Power

Power Supply	AC 100-240V~, 50/60Hz
Power Type	Built-In Power

Power Consumption

Typ.	210 W
Max.	250 W
Smart Energy Saving	110 W
DPM	0.5 W
Power off	0.5 W
BTU (British Thermal Unit)	717 BTU/Hr(Typ.), 853 BTU/Hr(Max)

Certification

Safety	CB / NRTL
EMC	FCC Class "B" / CE / KC
ErP	Yes (EU Only)

Media Player Compatibility

OPS type compatible	Yes (Piggyback)

Software Compatibility

SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Media Editor, LG ConnectedCare

Accessory

Basic	Remote Controller(include battery 2ea), Power Cord, RS232C cable, Lan calbe, DP cable, IR Receiver, Guide Bracket, Screws, Manual
Optional	OPS Kit (KT-OPSF)
