| Supported Display Resolution |
|
| Computer formats |
1024 x 768, 60, 70, 75 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 1280 x 800, 60 Hz, 1440 x 900, 60 Hz, 1600 x 1200, 60 Hz, 1680 x 1050, 60 Hz, 1920 x 1080, 60 Hz, 3840 x 2160, 60 Hz |
| Video formats |
1080p, 50, 60 Hz, 1080i, 50, 60 Hz, 720p, 50,60 Hz, 2160p, 50, 60 Hz |
|
|
| Connectivity |
|
| Video input |
HDMI 2.0 (x 2), USB 2.0 (x 2), DVI-I (x 1), USB 3.0 (x1) |
| Audio input |
3.5 mm jack |
| Audio output |
3.5 mm jack |
| External control |
RJ45 |
|
RS232C (in/out) 2.5 mm jack |
|
IR (in/out) 3.5 mm jack |
| Other connections |
micro SD |
|
|
| Convenience |
|
| Energy-saving functions |
Smart Power |
| Tiled Matrix |
Up to 3 x 3 |
| Keyboard control |
Lockable |
|
Hidden |
| Network controllable |
RS232 |
|
RJ45 |
| Signal loop through |
RS232 |
|
IR Loop through |
| Placement |
Landscape (18/7) |
|
Portrait (18/7) |
| Remote control signal |
Lockable |
|
|
| Dimensions |
|
| Bezel width |
13.9 mm (Even bezel) |
| Set Width |
973.0 |
| Set Height |
561.2 |
| Set Depth |
63.5 mm |
| Set Width (inch) |
38.31 |
| Set Height (inch) |
22.09 |
| Set Depth (inch) |
2.50 |
| Wall Mount |
200 mm x 200 mm, M6 |
| Product weight |
11.29 |
| Product weight (lb) |
24.91 |
|
|
| Operating conditions |
|
| Temperature range (operation) |
0 ~ 40 |
| Temperature range (storage) |
-20 ~ 60 |
| MTBF |
50.000 |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
| Altitude |
0 ~ 3000 m |
|
|
| Power |
|
| Mains power |
100–240 V~, 50/60 Hz |
| Standby power consumption |
<0.5 W |
| Consumption (Max) |
170 W |
| Consumption (Typical) |
96 |
| Power Saving Features |
Smart Power |
| Energy Label Class |
G |
|
|
| Sound |
|
| Built-in speakers |
2 x 10 W RMS |
|
|
| Multimedia Applications |
|
| USB Playback Video |
MPEG, H.264, H.263, H.265, AVI, MP4, VP8 |
| USB Playback Picture |
BMP, JPEG, PNG |
| USB Playback Audio |
AAC, HEAAC, MPEG |
|
|
| Accessories |
|
| Included Accessories |
IR sensor cable (1.8 m) (x 1), RS232 daisy-chain cable, Philips logo (x 1), AC Power Cord, AC Switch Cover, Quick start guide, Remote control and AAA batteries, RS232 cable, USB cover and screws, Wire Clamper (x 3) |
|
|
| Miscellaneous |
|
| Warranty |
3 year warranty |
| On-Screen Display Languages |
English, French, German, Italian, Polish, Turkish, Russian, Simplified Chinese, Spanish, Traditional Chinese, Arabic, Japanese |
| Regulatory approvals |
CB, CE, FCC, Class A, VCCI, RoHS, UL |
|
|
| Internal Player |
|
| CPU |
Quad Core Cortex A55 |
| GPU |
G52 MC1 |
| Memory |
16 GB |
|
3 GB DDR |
