| Supported Display Resolution |
|
| Computer formats |
1920 x 1080, 60 Hz, 1024 x 768, 60 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 1440 x 900, 60 Hz, 1600 x 900, 60 Hz, 1680 x 1050, 60 Hz, 640 x 480, 60 Hz, 800 x 600, 60 Hz
|
| Video formats |
1080i, 50, 60 Hz, 576i, 50 Hz, 576p, 50 Hz, 480p, 60 Hz, 480i, 60 Hz, 1080p, 50, 60 Hz, 720p, 50,60 Hz |
|
|
| Connectivity |
|
| Video input |
DVI-I (x 1), DisplayPort 1.4 (x 1), HDMI 2.0 (x 2), USB 3.0 (x 2), VGA (via DVI) |
| Video output |
DisplayPort 1.4 (x 1) |
| Audio input |
3.5 mm jack |
| Audio output |
3.5 mm jack |
| External control |
RJ45 |
|
RS232C (in/out) 2.5 mm jack |
|
IR (in/out) 3.5 mm jack |
| Other connections |
Micro USB (x 1) (OTG), USB 2.0 (x 1) |
|
|
| Convenience |
|
| Placement |
Landscape (24/7) |
|
Portrait (24/7) |
| Tiled Matrix |
Up to 10 x 15 |
| Keyboard control |
Hidden |
|
Lockable |
| Signal loop through |
RS232 |
|
IR Loop through |
|
DisplayPort |
| Network controllable |
RS232 |
|
External 4G mPCIe slot |
|
RJ45 |
| Energy-saving functions |
Smart Power |
|
|
| Dimensions |
|
| Set Width |
726.5 |
| Set Height |
425.4 |
| Set Depth |
65.1 (@Wall mount)/ 69.1 (@AC) |
| Set Width (inch) |
28.60 |
| Set Height (inch) |
16.75 |
| Set Depth (inch) |
2.56 (@Wall mount)/ 2.72 (@AC) |
| Bezel width |
11.9 mm (T/L/R), 17.2 mm (B) |
| Product weight (lb) |
12.57 |
| Product weight |
5.7 |
| Wall Mount |
100 (H) x 100 (V) mm / 200 (H) x 200 (V) mm, M4 |
|
|
| Operating conditions |
|
| Temperature range (operation) |
0 ~ 40 |
| Temperature range (storage) |
-20 ~ 60 |
| MTBF |
50.000 |
| Humidity range (operation)[RH] |
20~80% RH (No condensation) |
| Humidity range (storage) [RH] |
5~95% RH (No condensation) |
| Altitude |
0 ~ 3000 m |
|
|
| Power |
|
| Standby power consumption |
<0.5 W |
| Mains power |
100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption (Max) |
TBD |
| Energy Label Class |
G |
| Consumption (Typical) |
TBD |
|
|
| Sound |
|
| Built-in speakers |
2 x 10 W RMS |
|
|
| Multimedia Applications |
|
| USB Playback Video |
MPEG, MP4, MPEG4, H.264, H.263, H.265, AVI, VP8, VP9, WEBM |
| USB Playback Picture |
BMP, JPEG, PNG |
| USB Playback Audio |
AAC, HEAAC, MPEG |
|
|
| Accessories |
|
| Included Accessories |
IR sensor cable (1.8 m) (x 1), RS232 daisy-chain cable, Philips logo (x 1), AC Power Cord, AC Switch Cover, Quick start guide, Remote control and AAA batteries, RS232 cable, USB cover and screws, Wire Clamper (x 3) |
|
|
| Miscellaneous |
|
| Warranty |
3 year warranty |
| On-Screen Display Languages |
English, French, German, Italian, Polish, Turkish, Russian, Simplified Chinese, Spanish, Traditional Chinese, Arabic, Japanese, Danish, Dutch, Finnish, Norwegian, Portuguese, Swedish |
| Regulatory approvals |
CE, CCC, RoHS, CB, EMF, FCC, Class A, EnergyStar 8.0, UL |
|
|
| Internal Player |
|
| CPU |
2 x A72 + 4 x A53 |
| GPU |
ARM Mali-T860 MP4 |
| Memory |
4 GB RAM |
| Storage |
32 GB eMMc |
outline-drawing-philips-32bdl4650d-v10-20230410
