| Connectivity |
|
| Audio output |
3.5 mm Mini Jack (x 1), SPDIF |
| Video input |
HDMI 2.0 (x 3), VGA (Analogue D-Sub) (x 1), USB-C (up to 65 W), USB 2.0 (x 1), USB 3.0 (x 4) |
| Audio input |
3.5 mm mini jack (x 1) |
| Other connections |
OPS, USB-B (x 2) |
| External control |
RS232C (in) D-Sub9, RJ45 x 2 |
| Bluetooth |
BT5.2 |
|
|
| Convenience |
|
| Remote control signal |
Lockable |
| Screen-saving functions |
Pixel Shift, Low Brightness |
| Placement |
Landscape (16/7) |
| Network controllable |
RS232, RJ45 |
| Other convenience |
Carrying handles |
| Keyboard control |
Lockable |
|
|
| Accessories |
|
| Accessories |
Power code (US, UK, EU), HDMI cable, USB-A to B, Remote control and AAA batteries, 2 pcs stylus, Quick start guide, Wall mount |
|
|
| Internal Player |
|
| Storage |
32 GB eMMc |
| Memory |
4 GB RAM |
| GPU |
Multi-Core Mali-G52 |
| CPU |
Quad-Core Cortex A55 |
| Wi-Fi |
2.4/5 GHz |
|
|
| Supported Display Resolution |
|
| Video formats |
480i, 60 Hz, 480p, 60 Hz, 720p, 50, 60 Hz, 1080i, 50, 60 Hz, 1080p, 50, 60 Hz, 2160p, 30, 60 Hz |
|
|
| Interactivity |
|
| Protection glass |
Anti-Glare, Tempered safety glass 7 MOHS |
| Multi-touch technology |
0-gap Infrared touch |
| Plug and play |
HID compliant |
| Touchpoints |
50 simultaneous touch points(depending on application) |
|
|
| Sound |
|
| Built-in speakers |
2 x 16 W |
|
|
| Power |
|
| Energy Label Class |
G |
| Consumption (Typical) |
180 W |
| Power Saving Features |
Smart Power |
| Standby power consumption |
<0.5 W |
| Mains power |
100 ~ 240 VAC, 50/60 Hz |
|
|
| Multimedia Applications |
|
| USB Playback Picture |
BMP, JPEG, PNG |
| USB Playback Video |
H.263, H.264, H.265, MPEG1/2, MPEG4, VP8 |
| USB Playback Audio |
AAC, MPEG, HEAAC |
|
|
| Operating conditions |
|
| Temperature range (storage) |
-20~60 °C |
| Temperature range (operation) |
0 ~ 40 °C |
| Humidity range (storage) [RH] |
10–90% (without condensation) |
| Altitude |
0 ~ 5000 m |
| Humidity range (operation)[RH] |
10–90% (without condensation) |
| MTBF |
30,000 hour(s) |
|
|
| Miscellaneous |
|
| On-Screen Display Languages |
Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese |
| Regulatory approvals |
CE, FCC, Class A, RoHS, CB, EAC, EMF, ETL, Energy Star 8.0 |
| Warranty |
5-year warranty |
|
|
| Weight |
|
| Product without stand (kg) |
59.2 kg |
| Product with packaging (lb) |
165.35 lb |
| Product without stand (lb) |
130.51 lb |
| Product with packaging (kg) |
75 kg |
|
|
| Dimensions |
|
| Set Height |
1159.9 mm |
| Wall Mount |
800 x 600 mm, M8 |
| Bezel width (L/R, T/B) |
16.6 mm (L/R/T)/45.0 mm (B) |
| Set Width |
1957 mm |
| Set Width (inch) |
77.05 inch |
| Set Depth |
95.5 mm |
| Set Depth (inch) |
3.94 inch |
| Set Height (inch) |
45.67 inch |
86bdl3152e-00-2023-12-14-10h10m36s
