Philips 65BDL3152E/00 65'' E-Line Interactive Education Display with Android
Product code:This interactive display maximises engagement and inspires collaboration with up to 40 touchpoints. Powered by Android 13 and with toughened anti-glare and anti-reflection glass, it's made to withstand heavy daily use in busy environments.
SEND AN ENQUIRYDescription
| Picture/Display | |
| Panel resolution | 3840 x 2160 |
| Brightness | 350 cd/m² |
| Pixel pitch | 0.372 (H) x 0.372 (V) [mm] |
| Diagonal screen size (metric) | 163.9 cm |
| OS UI resolution | 1920 x 1080 @ 60 Hz |
| Display colours | 1.07 B |
| Optimum resolution | 3840 x 2160 @ 60 Hz |
| Picture enhancement | 3/2 - 2/2 motion pull down, 3D Combfilter, Motion compens. Deinterlacing, Progressive scan, 3D MA deinterlacing, Dynamic contrast enhancement |
| Viewing angle (horizontal) | 178 degree |
| Aspect ratio | 0,672916667 |
| Viewing angle (vertical) | 178 degree |
| Diagonal screen size (inch) | 65 inch |
| Response time (typical) | 8 ms |
| Panel technology | ADS |
| Contrast ratio (typical) | 50,00069444 |
| Operating system | Android 13 |
Additional information
| Connectivity | |
| Audio output | 3.5 mm Mini Jack (x 1), SPDIF |
| Video input | VGA (Analogue D-Sub) (x 1), USB-C (up to 65 W), HDMI 2.0 (x 3), USB 2.0 (x 1), USB 3.0 (x 4) |
| Audio input | 3.5 mm mini jack (x 1) |
| Other connections | OPS, micro SD, USB-B (x 3) |
| External control | IR (in/out) 3.5 mm jack, RS232C (in/out) 2.5 mm jack, RJ45 x 2 |
| Convenience | |
| Ease of installation | AC Out, Smart Insert |
| Remote control signal | Lockable |
| Screen-saving functions | Pixel Shift, Low Brightness |
| Placement | Landscape (16/7) |
| Network controllable | RS232, RJ45 |
| Other convenience | Carrying handles |
| Keyboard control | Lockable |
| Signal loop through | RS232, IP Loop through |
| Supported Display Resolution | |
| Video formats | 480i, 60 Hz, 480p, 60 Hz, 720p, 50, 60 Hz, 1080i, 50, 60 Hz, 1080p, 50, 60 Hz, 2160p, 30, 60 Hz, 576i, 50 Hz, 576p, 50 Hz |
| Computer formats | 720 x 400, 70 Hz, 832 x 624, 75 Hz, 1440 x 900, 60 Hz, 1600 x 900, 60 Hz, 1680 x 1050, 60 Hz, 1920 x 1080, 60 Hz, 1024 x 768, 60 Hz, 1152 x 870, 75 Hz, 1280 x 1024, 60 Hz, 1280 x 720, 60 Hz, 3840 x 2160, 30, 60 Hz, 640 x 480, 60, 67, 75 Hz, 800 x 600, 60 Hz |
| Interactivity | |
| Protection glass | Anti-Glare, Tempered safety glass 7 MOHS |
| Multi-touch technology | 0-gap Infrared touch |
| Plug and play | HID compliant |
| Touchpoints | 40 simultaneous touchpoints |
| Accessories | |
| Optional accessories | Interact dongles |
| Included Accessories | Cleaning cloth (x 1), HDMI Cable (3 m) (x 1), IR sensor cable (1.8 m) (x 1), Philips logo (x 1), Quick start guide (x 1), Remote control and AAA batteries, RS232 daisy chain cable (x 1), Touch Pen (x 2), USB A to B cable (3 m) (x 1), RS232 cable, AC Power Cord, Cable clip (x 3), AC, switch cover and Screw x 1, DVI-D cable, USB cover and screws |
| Internal Player | |
| Storage | 32 GB eMMc |
| Memory | 4 GB RAM |
| GPU | Multi-Core Mali-G52 |
| CPU | Quad Core Cortex A55 |
| Sound | |
| Built-in speakers | 2 x 16 W |
| Power | |
| Energy Label Class | G |
| Consumption (Typical) | TBD W |
| Power Saving Features | Smart Power |
| Standby power consumption | <0.5 W |
| Consumption (Max) | TBD |
| Mains power | 100 ~ 240 VAC, 50/60 Hz |
| Multimedia Applications | |
| USB Playback Picture | BMP, JPEG, PNG |
| USB Playback Video | H.263, H.264, H.265, MPEG1/2, MPEG4, VP9 |
| USB Playback Audio | AAC, MPEG, HEAAC |
| Operating conditions | |
| Temperature range (storage) | -20~60 °C |
| Temperature range (operation) | 0 ~ 40 °C |
| Humidity range (storage) [RH] | 10–90% (without condensation) |
| Altitude | 0 ~ 5000 m |
| Humidity range (operation)[RH] | 10–90% (without condensation) |
| MTBF | 50,000 hour(s) |
| Miscellaneous | |
| On-Screen Display Languages | Arabic, Dutch, Danish, English, French, Finnish, German, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Spanish, Swedish, Simplified Chinese, Turkish, Traditional Chinese |
| Regulatory approvals | CE, FCC, Class A, RoHS, CB, EAC, EMF, ETL |
| Warranty | 5-year warranty |
| Weight | |
| Product without stand (kg) | 35 kg |
| Product with packaging (lb) | 98.55 lb |
| Product without stand (lb) | 77.16 lb |
| Product with packaging (kg) | 44.7 kg |
| Dimensions | |
| Set Height | 896 mm |
| Wall Mount | 600 x 400 mm, M8 |
| Set Width | 1488 mm |
| Set Width (inch) | 58.58 inch |
| Set Depth | 87 mm |
| Set Depth (inch) | 3.43 inch |
| Smart Insert mount | TBD |
| Bezel width | TBD |
| Weight | 35 kg |
| Set Height (inch) | 35.28 inch |
