LG LAEC015-GN2 LED 1.56 Pixel Pitch All-in-One Smart Series
Product code:- Pixel Pitch: 1.56 mm
- Screen Size: 136" (Full HD)
- Brightness: 500 nit
- Embedded System Controller
- Built-in Speaker
- Dedicated Accessories : Wall Mount, Motorized Stand (Optional)
Description
Physical Parameter
| Pixel Configuration | Single SMD |
|---|---|
| Pixel Pitch (mm) | 1.56 |
| Module Dimensions (W x H, mm) | 250 x 281.25 |
| Screen Resolution (WxH) | 1,920 x 1,080 |
| Screen Dimension (W x H x D,mm) | 3,004 x 1,692 × 36.5 (Thickest 70) |
| Screen Weight (kg) | 135 |
| No. of Modules per Screen (W x H) | 12 x 6 (Total 72) |
| Screen Surface Area (㎡) | 5.06 |
| Physical Pixel Density (pixels/m²) | 409,600 |
| Flatness of Cabinet | ±0.2 mm |
| Cabinet Material | Aluminum |
| Service Access | Front |
Additional information
Optical Parameter
| Brightness | 500 nit |
|---|---|
| Color Temperature (K) | 7,300 |
| Visual Viewing Angle (Horizontal/Vertical) | 160 / 160 |
| Brightness Uniformity | 98% |
| Color Uniformity | ±0.015Cx,Cy |
| Contrast Ratio | 3000 : 1 |
| Processing Depth (bit) | 16 |
Electrical Parameter
| Power Consumption (W/Screen, Max.) | 1,700 |
|---|---|
| Power Consumption (W/Screen, Avg.) | 560 |
| Power Consumption (W/m², Max.) | 336 |
| Power Consumption (BTU/h/Screen, Max.) | 5,801 |
| Power Consumption (BTU/h/Screen, Avg.) | 1,911 |
| Power Consumption (BTU/h/㎡, Max.) | 1,146 |
| Power Supply (V) | 100 to 240 |
| Frame Rate (Hz) | 50 / 60 |
| Refresh Rate (Hz) | ≥ 2,880 |
Operation Conditions
| Lifetime (Hours to Half Brightness) | 100,000 |
|---|---|
| Operating Temperature (°C) | 0℃ to +40℃ |
| Operating Humidity | <90%RH (without condensation) |
| IP rating Front / Rear | IP30 / IP20 |
Sound
| Speaker | Built-in (9W + 9W) |
|---|
Certification
| Certification | CE, FCC, ETL, CB |
|---|
Environment
| Environment | RoHS, REACH |
|---|
Controller
| Controller | Embedded |
|---|
