LG 98UM5J UHD Large Screen Digital Signage Display
Product code:Being slim, a closer installation to the wall is advised. Additionally, this increases the screen’s immersive experience and provides a sophisticated design, improving the installed-space’s décor.
SEND AN ENQUIRYDescription
Panel
| Screen Size | 98" |
|---|---|
| Panel Technology | IPS |
| Native Resolution | 3,840 X 2,160 (UHD) |
| Refresh Rate | 60 Hz |
| Brightness (Typ.) | 500 nit |
| Contrast Ratio | 1,200 : 1 |
| Dynamic CR | 200,000 : 1 |
| Color gamut | DCI 85% |
| Viewing Angle (H x V) | 178 Deg.(H) × 178 Deg.(V) |
| Color Depth | 1.07 Billon Colors (8bit + FRC) |
| Response Time | 8 ms |
| Surface Treatment | 25 % |
| Life Time (Typ.) | 30,000 Hrs |
| Operation Hours (Hours / Days) | 16 / 7 |
| Portrait / Landscape | Yes / Yes |
| OS | webOS |
Additional information
Mechanical Specification
| Bezel Color | Black |
|---|---|
| Bezel Width | 17 mm (T/R/L/B) |
| Weight (Head) | 78 kg |
| Monitor Dimensions (W × H × D) | 2,198 × 1,253 × 79.5 mm |
| VESA™ Standard Mount Interface | 800 × 400 mm or 800 × 800 mm |
Feature
| Key Feature | Internal Memory (16 GB) (Based on EMMC), Wi-Fi (Built-in, FW update only), Bluetooth (Built-in), Power Indicator, Local Key Operation (7 Key, Power / UP / DOWN / LEFT / RIGHT / INPUT / MENU), webOS Non Smart / Non webOS Platform, Screen Rotation (Only 98”(Manually Change)), HDMI-CEC |
|---|
Connectivity
| Input | HDMI (3), RJ45(LAN) (1, FW update only), IR IN (No, Built-in IR), USB2.0 Type A (2) |
|---|---|
| Output | Audio Out (SPDIF, Phone Jack) |
Environment Conditions
| Operation Temperature | 0°C to 40°C |
|---|---|
| Operation Humidity | 10 % to 80 % |
Power
| Power Supply | AC 100-240 V~, 50/60 Hz |
|---|---|
| Power Type | Built-In Power |
Power Consumption
| Typ./Max. | 560 W / 590 W |
|---|---|
| Power off | 0.5 W |
| BTU (British Thermal Unit) | 1,706 BTU/Hr (Typ.), 1,911 BTU/Hr (Max.) |
Sound
| Speaker | Yes (10 W+10 W) |
|---|
Certification
| Safety | UL, CB |
|---|---|
| EMC | FCC Class “A” / CE |
| ErP | Yes (NewErP) |
Accessory
| Basic | LG Remote Controller, Power Cord, Manual |
|---|
Datasheet
