LG 86UH5J-H New High Haze UHD Standard Digital Signage
Product code:With a recommend brightness of 500 cd/m² for an indoor display, the UH5J-H series clearly deliver content and attract public attention, making it the most suitable display for marketing in meeting rooms, airports, retail, shopping malls etc.
Description
Panel
| Screen Size | 86" |
|---|---|
| Panel Technology | IPS |
| Back Light Type | Edge |
| Aspect Ratio | 16 : 9 |
| Native Resolution | 3,840 X 2,160 (UHD) |
| Refresh Rate | 120 Hz |
| Brightness | 500 nit (Typ.) |
| Contrast Ratio | 1,100 : 1 |
| Dynamic CR | 1,000,000 : 1 |
| Color gamut | NTSC 72% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 1.07 Billon Colors (10 bit) |
| Response Time | 8 ms (G to G) |
| Surface Treatment | 28% |
| Life Time (Typ.) | 50,000 Hrs |
| Operation Hours (Hours / Days) | 24 / 7 |
| Portrait / Landscape | Yes / Yes |
| OS | webOS 6.0 |
Additional information
Mechanical Specification
| Bezel Color | Black |
|---|---|
| Bezel Width | 14.3 mm (Even Bezel) |
| Weight (Head) | 49 kg |
| Monitor Dimensions (W × H × D) | 1,926.2 × 1,097.2 × 60.6 mm (without Handle and LG Logo) |
| VESA™ Standard Mount Interface | 600 × 400 mm |
Connectivity
| Input | HDMI (2, HDCP 2.2/1.4), HDMI (HDCP 1.4), DP (HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio In, RS-232C In (4 Pin Phone-jack), RJ45 (LAN), IR In, USB 2.0 (2, Type A) |
|---|---|
| Video / Audio | HDMI Out, Audio Out, External Control (RS-232C Out (4 Pin Phone-jack)) |
Environment Conditions
| Operation Temperature | 0°C to 40°C |
|---|---|
| Operation Humidity | 10% to 80% |
Power Consumption
| Typ./Max. | 215 W / 280 W (TDB) |
|---|---|
| Smart Energy Saving | 150.5 W (TDB) |
| DPM | 0.5 W |
| Power off | 0.5 W |
| BTU (British Thermal Unit) | 733.69 BTU/Hr (Typ.), 955.5 BTU/Hr (Max.) (TDB) |
Certification
| Safety | CB / NRTL |
|---|---|
| EMC | FCC Class "A" / CE / KC |
| ErP / Energy Star | Yes (NewErP) / No (TDB) |
Software Compatibility
| SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Media Editor, Promota (Not Available for EU/CIS), Mobile CMS, LG ConnectedCare |
Language
| English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portugues (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues (Europe), Dutch, Czech, Greek, Turkish, Arabic |
Accessory
| Basic | Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender |
|---|
Key Feature
| Internal Memory 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor, Acceleration (Gyro) Sensor), Local Key Operation, webOS 6.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Multi-screen (PIP, PBP (4)), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected®), Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready (Except 98”/86”/75”)), Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom |
Datasheet
