LG 65EP5G UltraFine Display OLED Pro
Product code:Enhance your workplace with LG’s 65EP5G OLED professional monitor that has been developed to meet a variety of use cases and workflows in content production, post-production and distribution.
SEND AN ENQUIRYDescription
Panel
| Screen Size | 65" |
|---|---|
| Panel Technology | OLED |
| Native Resolution | 3,840 X 2,160 (UHD) |
| Brightness | 950 / 850 / 450 / 175 @D65 (APL 3% / 10% / 25% / 100%) |
| Contrast Ratio | 1,850,000 : 1 |
| Color gamut | DCI-P3 98.5% |
| Viewing Angle (H x V) | 178 × 178 |
| OS | webOS 5.0 |
| Color Depth | 1.07 Billion Colors (10 bit) |
| Operation Hours (Hours / Days) | 12 / 7 (Moving Content Only) |
| Portrait / Landscape | No / Yes |
Additional information
Mechanical Specification
| Bezel Color | Black |
|---|---|
| Bezel Width | Off Bezel : 2.0 / 2.0 / 2.0 / 2.0 mm (T/R/L/B) On Bezel : 8.7 / 8.9 / 8.9 / 11.6 mm (T/R/L/B) |
| Weight (Head) | 31 kg |
| Weight (Head+Stand) | 35 kg |
| Packed Weight | 45.5 kg |
| Monitor Dimensions (W × H × D) | 1,446.3 × 853.8 × 56.5 mm (w/ Control Box) |
| Monitor Dimensions with Stand (W × H × D) | 1,446.3 × 896.5 × 272 mm |
| Carton Dimensions (W × H × D) | 1,670 × 200 × 1,108 mm (Box Outer Size) |
| Handle | Yes |
| VESA™ Standard Mount Interface | 300 × 300 mm |
Key Feature
| SW | webOS 5.0, Multi-screen (PIP, PBP (2)) |
|---|---|
| Picture | Color Adjustment (OLED Light, Contrast, Chroma, Sharpness, Tint), Color Temp (VAR / 9300 K / 6500 K / 5400 K / 3200 K / D65 (6504 K) / C (6774 K) / D-Cinema (6302 K)), Over Scan (Zero Scan, Over Scan, Under Scan), Aspect Ratio (Full Wide, 4:3, 14:9, 13:9, 1.85:1, 2.35:1, 1:1, Original), AFD (Active Format Description) (Yes), Zoom (×2 ~ ×5), HDR / SDR Monitoring (Yes), 3rd Party Cal. SW Compatibility (CalMAN - Including Uniformity Compensation, 9 p / 13 p / 25 p, EBU Grade1) (LG Connect must be on.), Eyesafe Certification (Less than 50% of Blue Light Emission) (Yes), Color Accuracy : DeltaE < 2 (Yes) |
| Color | Gamut (Native, P3, BT.709, SMPTE-C, BT.2020, EBU, Adobe RGB, NTSC), SDI Color Format (Auto, RGB444, YCbCr444, YCbCr422), R/G/B Gain (-768 ~ 255), Mono/Blue Only, Transfer Matrix, Mastering Peak, EOTF (Auto / User / 1.9 / 2.2 / 2.4 / 2.6 / SDR (Calibration) / ST.2084 PQ / BT.2100 HLG / HDR (Calibration) / Dolby Vision / Dolby Vision (Calibration)) |
| Marker | Marker, Safety Area, Center Marker |
| Audio | Audio Level Meter (Ch1~16, Selectable), Dolby Atmos (2Ch, Down Mix through Audio Out Port) |
| GPI | GPI Control (General Purpose Interface) |
| Video Analysis | Waveform, Vector Scope, Time Code (LTC, VITC), PIP/PBP |
| Advanced | Profile Load / Save (Profile 1~10), Function Key (Function1~5), Tally, Gen Lock, LG Connect, 3rd Party Control Pad Compatibility (Open API), Remote IP Control App (HTML) |
Connectivity
| Input | HDMI (2, (HDCP1.4/2.2, HDMI2.1)), SDI (4, 12G × 4, Single Link : SD / HD / 3G / 6G / 12G, Dual Link : HD / 3G_4K , Quad Link : HD_4K / 3G_4K, Quad View : SD / HD / 3G / 6G / 12G), REF (Black Burst, Tri-Level), USB 2.0 Type A (SW update, & Calibration), Power (AC) |
|---|---|
| Output | Audio (Head-Phone), SDI (4, Loop-through) |
| External Control | RS-232C In (Service Only), RJ45 (LAN, 100base-T) In, RJ45 (Remote, GPI 7port) In / Out, SFP In (SFP+, Support Only for The Embrionix's SFP Module), IR In |
Environment Conditions
| Operation Temperature | 0 °C to 40 °C |
|---|---|
| Operation Humidity | 10 % to 80 % |
Power
| Power Supply | AC 100-240V~, 50/60Hz |
|---|
Power Consumption
| Typ./Max. | 300 W / 470 W |
|---|---|
| BTU (British Thermal Unit) | 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.) |
Certification
| Safety | CB / NRTL |
|---|---|
| EMC | FCC Class "A" / CE / KC |
| ErP | Yes (EU Only) |
Software Compatibility
| SuperSign WB | Yes |
|---|---|
| CalMAN SW Compatibility | Yes |
| IP Remote Utility | Yes |
Language
| OSD | English, Korean |
Accessory
| Basic | Remote Controller, IG (Installation Guide), Regulation Book |
|---|
