LG 55EJ5G-B Full HD Wallpaper OLED with Ultra Slim Bezel
Product code:This sophisticated wallpaper OLED signage achieves the best possible picture quality, concealing its presence by blending in with the wall. Minimal space is required for installation, which simplifies the construction process. The luxurious atmosphere generated with this signage will provide customers with an extraordinary experience, making them feel like VIPs.
SEND AN ENQUIRYDescription
Panel
| Screen Size | 55" |
|---|---|
| Panel Technology | OLED |
| Native Resolution | 1,920 x 1,080 (FHD) |
| Brightness | 150/400 nit (APL 100% / 25%) |
| Contrast Ratio | 150,000 : 1 |
| Color gamut | BT709 120% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 10 bit (R), 1.07 Billion Colors |
| OS | webOS 4.0 |
| Operation Hours (Hours / Days) | 18 / 7 (Moving Content Only) |
| Portrait / Landscape | Yes / Yes |
Additional information
Mechanical Specification
| Bezel Color | Black |
|---|---|
| Bezel Width | *TBD 0.9 mm (Even Bezel) (Off Bezel) 5.3 / 11.0 / 5.3 / 5.3 mm (T/R/L/B) (On Bezel) |
| Weight (Head) | *TBD 6.6 kg (Head) 3.4 kg (Signage Box) |
| Monitor Dimensions (W × H × D) | *TBD 1,220.3 × 696.8 × 4.9 mm (Head) 782.8 × 238.4 × 34.7 mm (Signage Box) |
Key Feature
| Internal Memory (16 GB), Temperature Sensor, webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Connected® (Network based control), Power (PM Mode, Wake on LAN), HDMI-CEC (Compatibility may differ by equipment), SI Server Setting, Pro:Idiom |
Connectivity
| Input | HDMI (HDCP 1.4), DP (HDCP 1.3), USB 2.0 Type A (2) |
|---|---|
| Output | DP, Audio |
| External Control | RS232C In / Out (w/ IR Out), RJ45 (LAN) In / Out, IR In (External IR Receiver) |
Environment Conditions
| Operation Temperature | 0°C to 40°C |
|---|---|
| Operation Humidity | 10 % to 80 % |
Power
| Power Supply | AC 100-240 V ~, 50/60 Hz |
|---|
Power Consumption
| Typ./Max. | 309 W / 318 W |
|---|---|
| BTU (British Thermal Unit) | 1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.) |
Certification
| Safety | IEC 60950-1 / EN 60950-1 / UL 60950-1 |
|---|---|
| EMC | FCC Class "A" / CE / KC |
| ErP | Yes |
Software Compatibility
| SuperSign WB | Yes |
|---|---|
| SuperSign CMS | Yes |
| SuperSign Control / Control+ | Yes |
| SuperSign Media Editor | Yes |
| LG ConnectedCare | Yes * The availability can differ by region. |
Language
| OSD | English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic |
Accessory
| Basic | Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, RS232 Cable (4p-4p), FFC Cables (1,600 mm × 4 EA for Connection between Panel and Signage Box), DP Cable, LAN Cable, LC (VLC Cable), Wall Fixer (4 EA), Wall Fixer Install Guide, Install Guide Sheet (2 EA), Tape (10 EA for Cabling / 2 EA for Dust Proof), Screw (M4 × L25, 10 EA / M3 × L5.5, 8 EA) |
|---|
