Philips QE-Line 55BDL3650QE/00 Digital Singage
Product code:Engage your audience with this environmentally conscious 4K Ultra HD digital display. Delivering uncompromised 4K UHD performance while running on half the power compared to other market models, with the very latest PPDS EcoDesign.
SEND AN ENQUIRYDescription
Picture/Display
| Pixel pitch | 0.315 x 0.315 mm |
|---|---|
| Panel resolution | 3840 x 2160 |
| Diagonal screen size (metric) | 138.7 cm |
| Brightness | 350 cd/m² |
| Picture enhancement | 3/2 - 2/2 motion pull down, Dynamic contrast enhancement, Motion compens. deinterlacing |
| Optimum resolution | 3840 x 2160 @ 60 Hz |
| Display colours | 1.06 Billion |
| Viewing angle (horizontal) | 178 degree |
| Dynamic contrast ratio | 500,000:1 |
| Aspect ratio | 16:9 |
| Response time (typical) | 8 ms |
| Operating system | Android 10 |
| Diagonal screen size (inch) | 54.6 inch |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle (vertical) | 178 degree |
| Panel technology | IPS |
Additional information
| Connectivity | |
| Optional WiFi functionality | CRD22 Wi-Fi dongle |
| Audio output | 3.5 mm jack |
| Video input | HDMI 2.0 (x 2), DVI-I (x 1), USB 2.0 (x 2), USB 3.0 (x 2) |
| Other connections | micro SD |
| Audio input | 3.5 mm jack |
| External control | RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack |
| Convenience | |
| Remote control signal | Lockable |
| Placement | Landscape (18/7) |
| Portrait (18/7) | |
| Energy-saving functions | Smart Power |
| Network controllable | RS232, RJ45 |
| Tiled Matrix | Up to 15 x 15 |
| Signal loop through | RS232, IR Loop through |
| Keyboard control | Lockable, Hidden |
| Internal Player | |
| Memory | 16 GB, 3 GB DDR |
| GPU | G52 MC1 |
| CPU | Dual-core cortex A53 1.1 GHz |
| Dual-core cortex A73 1.15 GHz | |
| Quad-Core Cortex A55 | |
| Sound | |
| Built-in speakers | 2 x 10 W RMS |
| Power | |
| Energy Label Class | D |
| Power Saving Features | Smart Power |
| Consumption (Typical) | 70 W |
| Mains power | 100–240 V~, 50/60 Hz |
| Standby power consumption | <0.5 W |
| Consumption (Max) | 120 W |
| Accessories | |
| Included Accessories | IR sensor cable (1.8 m) (x 1) |
| RS232 daisy-chain cable | |
| Philips logo (x 1) | |
| AC Power Cord | |
| AC Switch Cover | |
| Cable clip (x2) | |
| Quick start guide | |
| RS232 cable | |
| USB Cover (x 1) | |
| Dimensions | |
| Set Height | 712.6 mm |
| Wall Mount | 400 mm x 400 mm, M6 |
| Set Width | 1241.8 mm |
| Set Depth | 63.6 mm |
| Set Width (inch) | 48.89 inch |
| Product weight (lb) | 37.92 lb |
| Product weight | 17.2 kg |
| Bezel width | 14.9 mm (Even bezel) |
| Set Height (inch) | 28.06 inch |
| Set Depth (inch) | 2.50 inch |
| Multimedia Applications | |
| USB Playback Picture | JPEG, BMP, PNG |
| USB Playback Video | H.263, H.264, H.265, MPEG1/2, MPEG4, VP8, VP9 |
| USB Playback Audio | AAC, HEAAC, MPEG |
| Miscellaneous | |
| On-Screen Display Languages | English, French, German, Italian, Polish, Russian, Spanish, Turkish, Simplified Chinese, Traditional Chinese, Arabic, Japanese |
| Regulatory approvals | CE, CB, BSMI, FCC, Class A, VCCI, J-Moss, ETL, RoHS |
| Warranty | 3 year warranty |
| Operating conditions | |
| Temperature range (storage) | -20 ~ 60 °C |
| Altitude | 0 ~ 3000 m |
| Humidity range (operation)[RH] | 20~80% RH (No condensation) |
| Temperature range (operation) | 0 ~ 40 °C |
| Humidity range (storage) [RH] | 5~95% RH (No condensation) |
| MTBF | 30,000 hour(s) |
| Supported Display Resolution | |
| Video formats | 1080p, 50, 60 Hz |
| 1080i, 50, 60 Hz | |
| 3840 x 2160p, 24, 25, 30, 60 Hz | |
| 480i, 60 Hz | |
| 480p, 60 Hz | |
| 720p, 50,60 Hz | |
| Computer formats | 832 x 624, 75 Hz |
| 1024 x 768, 60, 70, 75 Hz | |
| 1152 x 864, 75 Hz | |
| 1152 x 870, 75 Hz | |
| 1280 x 1024, 60 Hz | |
| 1280 x 720, 60 Hz | |
| 1280 x 800, 60 Hz | |
| 1440 x 900, 60 Hz | |
| 1600 x 1200, 60 Hz | |
| 1680 x 1050, 60 Hz | |
| 1920 x 1080, 60 Hz | |
| 3840 x 2160, 24, 25, 30, 60 Hz | |
| 640 x 480, 60, 67, 72, 75 Hz | |
| 720 x 400, 70 Hz | |
| 800 x 600, 56, 60, 72, 75 Hz |
