Edbak RPWS1 Heavy duty wall swivel arm for 42″-70″ screens
Product code:Swivel wall arm RPWS1, is dedicated to large and heavy screens with diagonal from 42″ up to 70″ and maximum load up to 120 kg. Three rotation axes allow any adjustment of the screen position landscape. The ability to tilt the screen from 0° to +12° and rotate the screen right-left by 90° allow the user to adjust the position of the screen to suit his or her needs and improve comfort.
SEND AN ENQUIRYDescription
- Option of landscape or portrait
- Ability to tilt the screen from 0° to +12°
- Maximum load capacity of 120 kg
- Ability to rotate the screen right-left 90°
- Adjustable distance from the wall from 150 to 800 mm
- VESA universal standard
- Simple assembly
Additional information
| Index | RPWS1 |
| Category | Swing Arms Wall Mounts |
| Product group | Display Mounts |
| Color | Black |
| Warranty | Limited 5-years |
| Number of screens | 1 |
| Minimum screen size | 42″ |
| Maximum screen size | 70″ |
| Forward tilting | 0° |
| Forward tilting | +12° |
| Arm rotation | 90° |
| Left-right rotation | 180° |
| Maximum load | 120 kg |
| VESA Mounting Compatibility | 200×200 up to 600×400 |
| Product dimensions | W: 957 mm D: 145 mm H: 520 mm |
| Product weight | 23 kg (5 0.70 lb) |
| Max. distance from mounting surface | 813.5 mm (32.02″). |
| Min. distance from mounting surface | 145 mm (5.70″) |
| Max.mounting pattern | 600 mm x 460 mm (23.63 x 18.11″). |
| Min. mounting pattern | 200 mm x 95 mm (7.87 x 3.74″). |
