Edbak VWM2157 Menu Board Wall Mount, modular 2×1 for 50″-57″ Screens
Product code:VWM2157 is a robust and accurately manufactured menu board wall mount for two 50″-57″ screens mounted in landscape orientation. The mount is designed for quick and easy video wall expansion. Thanks to the modular concept, any configuration of the video wall can be arranged. The micro-adjustment system allows you to adjust the position of the screen very precisely and adjust it to the other monitors. The integrated cable routing system allows the cabling to be hidden, guaranteeing aesthetic appearance. VWM2157 is perfect for public areas and restaurants, wherever there is a need for frequent layout changes and dynamic communication with the audience.
SEND AN ENQUIRYDescription
- Quick and simple installation
- For mounting 2 x 50″-57″ screens
- Possibility of tilting the screen by 11°
- Durable aluminum structure
- Patented beam level adjustment system
- Universal VESA-compliant mounting range
- Possibility of easy extension with additional modules
Additional information
Product Specifications
| Index: | VWM2157 |
| Color: | Black |
| Warranty: | Limited 5-year’s |
| Number of screens: | 2 |
| Minimum screen size: | 50″ |
| Maximum screen size: | 57″ |
| Maximum load: | 160 kg |
| Forward tilting: | +11° |
| VESA Mounting Compatibility: | 50×50 up to 600×400 |
Technical Specifications
| Product dimensions: | W: 85,5 mm D: 2220 mm H: 455 mm
(W: 3,37″ D: 87,40″ H: 17,91″) |
| Product weight: | 14,5 kg (32 lb) |
| Max. mounting pattern: | 600 mm x 417,5 mm |
| Min. mounting pattern: | 50 mm x 50 mm |
Logistics Data
| SAP Index: | WUSC-VWM2157 |
| EAN Code: | 5902841136632 |
| HS Code (Harmonized System): | 732690 |
| HTS Code (Harmonized Tariff Schedule): | 7326909890 |
| Country of origin: | Poland |
